Description of open collector input mode: The single-ended input mode can use either the power supply
provided inside the drive or an external power supply. However, do not use dual power inputs to avoid damage to
the drive. Under normal circumstances, PLC controller systems use this position control wiring method
The pulse command input can be divided into differential signal input and open collector input. The differential
signal input receives a maximum frequency of 500K and the open collector input receives a maximum frequency of
200K.
6.1.4 Position Control Mode Parameter Description
1,motor and driver control parameters
Param
Code
Name
setting
range
setting
Note:
P01-01 Control mode setting
0: Position mode
1: Speed Mode
2: Torque mode
0-5
0
3: Speed, torque
4: Position, Speed
5: position, torque
P03-00 Location Command Source
0: pulse command
1: Reserved
0-3
0
2: Bus instruction
3: Built-in
