L1、L2（200/400W)
L1、L2、L3（750W)
L1、L2、L3（1500W)
U、V、W
Main circuit power input
terminal
Main circuit power input
terminal
Main circuit power input
terminal
Motor power line
connection end
P+、D、C
regenerative resistor
connection
PE Ground Port
Drive Protected Ground
Port
Single phase 220V AC, connected toL1/L2 port
Single-phase 220V AC, connected toL1/L2 port, L3
is empty pin
Single/Three phase 220V AC toL1/L2/L3 port
Connect the motor power line (connect the
corresponding interface according to the power line
mark)
When using the built-in regenerative resistor,
short-circuit P+ and D (our 750W and above drivers
have built-in regenerative resistors)
When using an external resistor, disconnect the P+
and D short wires, and connect both ends of the
resistor to the P+ and C terminals
Connect the ground wire of power supply and motor
Note:
1． Be sure to connect the electromagnetic contactor between the power supply and the main circuit power supply
of the servo driver, so that the power supply can be cut off in case of failure of the servo driver to prevent fire
caused by excessive current.
2． When the feedback energy exceeds the absorption capacity of the capacitor, E.402 overvoltage alarm will
occur. In this case, external regenerative resistance shall be connected, and P00-30~P00-35 shall be set to
corresponding values. See8.2 Parameter Analysis Description for details.
