2.2 servo motor
2.2.1 General
JAND-P28/DB44 series servo motor is a kind of high speed and high precision servo motor developed by
JMC to meet the requirements of modern automatic control. This series of servo motor can control the speed and
position accuracy very accurately, and can convert the voltage signal into torque and speed to drive the control
object. This series of servo motor rotor speed is controlled by the input signal, and can respond quickly, in the
automatic control system, used as the executive element, and has the electrical and mechanical time constant small,
high linearity, starting voltage and other characteristics, can receive the electrical signal into the motor shaft angular
displacement or angular velocity output, and can real-time feedback signal to the servo driver for adjustment, to
achieve high-precision control.
2.2.2 Main Features
1. high-energy magnetic force
2. Short time 300% overload capability
3. Flange size (mm): 40, 60, 80, 110, 130
4. Power: 0.1-1.5KW optional
5. Low noise, low heat, high precision, high speed, etc.
2.2.3 Servo motor nameplate and model description
1. Description of nameplate content
Motor type
Definition of motor power
Rated power, input
voltage, input current,
rated torque, rated speed,
encoder wire number
SERVO MOTOR
MODEL:6 0JASM504 230
K-17BC
MOTOR LEADS
U: RED V：BLACK W:WHITE
Pn:40 0W
AC: 220V In:2.8 A
Tn:1.2177Nm Nn:3000r/m En:17 bit
︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳︳
SER.NO:2023 01 01001
