100W
200/400/750/1500W DI5
Digital Input 5
GND/24V
DO123- Digital Output 123 Common
Negative
DO1+ Digital Output Port 1 Positive
GND
DO1+ high terminal
DO2+ Digital Output Port 2 Positive DO2+ high terminal
DO3+ Digital Output Port 3 Positive DO3+ high terminal
DO4+ Digital Output Port 4 Positive DO4+ high terminal
DO4- Digital Output Port 4 Negative DO4-Low terminal
Note:
1. For the custom function setting of digital input (DI) and output (DO) ports, please refer tothe parameter
description in Chapter 8.
3.2.1JAND-DB44 Servo Driver CN1 Control Port Definition
The upper control and driver connection interface is used for the upper computer to control the driver and the driver
feedback output
Definition of each pinof CN1terminal:
pin number
1
2
3
4
label
DO4+
DO3-
DO3+
DO2-
definition
digital output positive
Digital Output Negative
digital output positive
Digital Output Negative
5
DO2+
digital output positive
6
DO1-
Digital Output Negative
7
DO1+
digital output positive
25
Description
Custom output port
Custom output port
Custom output port
Custom output port
Custom output port
Custom output port
Custom output port
    "
