Arrange the parameters for each axis to ensure that each axis can move normally.
Axis selection: you can select axis X, axis Y, and focus axis.
Physical channel: select the point axis port, you can customize and
configure the axis number of each axis.
Axis direction: play debugging function. In processing page, click X
+, the torch will move to the X axis positive direction, the actual machine
on the X axis negative direction, this phenomenon shows the motor reverse, check
the axis direction reverse, in processing page, click X +, the page to the X
axis positive direction, the actual machine head will also move to the X axis
direction.
Number of pulses: the number of pulses to be sent when the machine moves
1mm along the X axis or Y axis.
Acceleration: the acceleration of machine movement.
Soft limit enable: enable the system soft limit function.
Positive and negative soft limit parameters: set the maximum minimum
of positive and negative soft limit for each axis.
Servo alarm enables: receive and respond to the servo alarm signal of
pin 14 in the servo interface, otherwise the signal will be responded.
Servo alarm input port: set the NO and nc type of servo alarm input
signal.
Zero enable: When enabled, the current axis will go back to zero,
otherwise the current axis will not go back to zero.
Back-zero order: Back-zero order of the currently selected axis. For
example, set to 1, indicating back to zero, the current selected axis will return
to zero first, and then the other axis back to zero.
Forward in the zero direction: set the zero direction of X / Y axis,
and the default is back to the negative direction of X / Y axis. Choose yes,
and then return to zero in the positive direction of the X-axis.
First return zero speed: the speed of the current axis for the first
time to find the approximate range of the return zero switch, so the speed
can be slightly larger.
Second return zero speed: the speed of the current axis at the second
time, the range of the return zero switch has been determined, so the speed
needs to be smaller to improve the accuracy of back to zero.
