[F1]: Graph management, there are 5 4 kinds of commonly used parts graphics library,
most of them have two kinds of piece size and hole size.
[F2]: File management, enter the optional hard disk files, disk files, find files,
edit files, delete files, copy to disk (copy to disk), preview graphics and other
operations.
[F3]: Part options, starting point selection, repeated arrangement (matrix,
staggered, stack), X mirror, Y mirror, select the number of rows, select hole number,
scale, code editing, figure restoration and other operations.
[F4]: Parameter setting, all parameters can be set here, global parameters, layer
process, user parameters, and system parameters.
[F5]: System diagnosis, input and output diagnosis, keyboard diagnosis, date and
time setting, physical port, system definition, etc.
[F6]: Elevator parameters, common parameters, system parameters, calibration,
diagnosis and additional functions.
[F7]: Customize, users can customize the display effect of the main interface, such
as: display shortcut key letters, display G code, display graphics size, display
artifact coordinates, display mechanical coordinates, display real-time speed, can
also configure the main interface shortcut function button.
[F8]: Platform configuration, input port definition, output port definition, shaft
configuration, machine tool configuration. Coordinate zero, before the machine
cutting, can set coordinate zero.( Z axis back to zero: the height controller has
a back to zero button。 The controller system will automatically set Z axis back
to zero before all axis back to zero)
[X]: Set the cutting speed.
[Y]: Set the manual moving speed.
[G]: Set the moving distance of fixed length. Note: After pressing G to modify the
length distance, the manual move mode will automatically switch to the length mode.
[F]: Set the manual moving mode, can set jog, continue and fixed distance.
[Z]: Can set the kerf value before or after cutting.
[-]: Switch monitor window.
[1] - [9]: The number key. In addition, during the operation of the system, pressing
these keys can quickly adjust the cutting speed to several percent of the maximum cutting
speed. For example, pressing [1] can adjusts the speed to 10%, and pressing [2] can
adjust the speed to 20%.
