Chapter 11 Platform configuration
Under the main interface, press [F 8] to enter the platform configuration
interface. As shown in the figure below, the platform configuration interface
function.
When entering the platform configuration interface, the system prompts the password to
input "1396", and press [Enter] to enter the configuration definition interface of the
system.
11.1 Input port definition
The controller can change the definition of the input IO port according to the needs
of the user, including the serial number of the changed IO port on the input terminal,
the NO or NC type of the input port, and the following 8 IO ports function definitions.
Press [F 8] to enter the configuration definition interface, and then press [F1] to
enter the input definition interface. As shown in Figure Figure 8.14.
Under this interface, press [↑], [↓], [←] and [→] on the operation panel, move
the cursor to the place to change the type or number, position the cursor to the option
to modify, press the [Enter] key to open the tab of the drop-down box where the cursor
is located, select through the [↑] and [↓] moving cursor, and press [Enter] again to
set the selected parameters again.
Serial number: 01~10,14~23.
Type: NO often open (low level effective), NC often closed (high level
effective).
Function: limit, emergency stop, gas alarm, laser alarm, water cooler alarm,
forward, backward, left, right, head alarm, deceleration input, torch up, torch
input, focus axis upper limit, focus axis lower limit, X axis zero input, Y) input
1, input 2,3, input 4,5,6,7 and 8.
