Side distance X: the distance between the edge from the X direction to the
edge after edge seeking, and offset to the board after setting.
Side distance Y: the distance between the edge from the Y direction to the
edge after edge seeking, and offset to the board after setting.
Edge seeking advanced parameters
Edge seeking sensitivity: the greater the edge seeking sensitivity, the more
sensitive.
Edge seeking follow intensity: there are two levels to choose, strong, weak.
Edge correction X: corner point offset X, correct the position of the edge point
based on the edge Angle.
Edge correction Y: corner point offset Y, correct the position of the edge point
based on the edge Angle.
Two-point distance X: the distance of the second point in the X direction, length
of X * set percentage.
Two-point distance Y: the distance of the second point in the Y direction, length
of X * set percentage.
Lift height after edge seeking: the height of the Z axis to be lifted after edge
seeking.
Specify the edge seeking starting point
Current position of cutting head: use the current position of cutting head
as the starting point of edge search.
Set the starting point: take the set position as the starting point, which
can get the current position or manually set.
specified position.
Note: Please return to the origin to correct the machine coordinate system, and
confirm whether the cutting head can follow normally before edge searching.
3.9.2 Two-point edge seeking
Two-point edge search is suitable for irregular plates containing a straight
edge. Compared with the three-point edge search, the two-point edge search can only
get the deflection Angle of the plate, can not find the processing zero, so after
the end of the two-point edge search, also need to manually move the cutting head
to the appropriate position for processing.
