M10
M00
M02/M30
No parameters
No parameters
No parameters
Turn off the
spray powder
pause
instruction
end of program
M07 perforated fixation cycle
Refer to Appendix 2 F4207V Series NC System IO timing chart.
M08 ends the cutting and fixation cycle
Refer to Appendix 2 F4207V Series NC System IO timing chart.
M00 pause
During the cutting process, the system will stop the machine tool when
encountering such instructions and wait for further operation.
M02 / M30 program ended
Chapter 14 Interface Description
The back interface diagram of this system, as shown in Figure Figure 11.1,
CN1 for the 3-core green terminal for the DC 24V power supply port
CN2 and CN3 are the input ports
CN4 and CN5 are the output ports
CN6 is an eight-core analog input and output port
The CN7 is a two-core PWM output port
A1, A2, A 3 and A4 are motor interfaces with standard DB15 male heads
CN8 is the serial port interface of RS232
CN9 is the high-frequency line interface of the height controller
The system contains Ethernet and Ether CAT network ports
Front / rear with two USB ports
