Cut peak power
%
Cut duty cycle
%
Cut pulse frequency Hz
The focus position mm
Cut residence time s
Lift height
mm
M08, do not close
power
Close power delay s
Enable focus
control
Manual speed of
Focus-axis
mm/min
Peak power in the process of the
maximum power of the laser (duty
cycle and pulse frequency of
real-time power. For example,
laser maximum power is 3000W,
cutting peak power is 50%, it
represents the system of the
cutting control laser power range
will not exceed 1500W, real-time
power represents the second power
is 800W, the next second power
control in 900W, is the real-time
value in the process of movement)
Proportion of the power-on time
relative to the total time within
a pulse cycle.
The number of times the signal
goes from high to low and returns
to high per second.
Location of the laser focus (energy
maximum point, similar to a
magnifying glass in the sun, can
focus a highest energy point)
Delay time before the torch start
moving (that is, when laser is
open, delay for a period of time,
otherwise starting cutting
directly)
After finish cutting, lift the torch
to set height.
Do not close the air valve when
performing the M08 lifting
When executing M08, delay a period
of time and then close the laser
Initiate the control of the focus
axis
Speed of manually move
focus-axis. The shortcut
[SHIFT] + [R] controls
110
