Small line segment fitting: when there are too many small line segments in
G code, there may be continuous jitter or vibration during the operation
of the machine tool. If this parameter is set to "yes", the system will fit
the small line segments into a complete curve, which can make the movement
smooth and continuously and reduce the jitter. In other cases, use No for
this parameter. When small line segment fitting is turned on, the
disadvantage is that the line segment accuracy will be partially reduced.
Optimization array G00: After checked, a new algorithm is used to optimize
the cutting path of the repeated pattern.
Display the perforation number: whether the perforation number is displayed
on the cut figure.
statistical information: Number of perforation: record the number of laser
perforation, can be manually cleared.
Number of pieces: record the number of parts processed by laser, can be manually
cleared.
Cutting distance: record the length of laser cutting and can be manually cleared.
Cutting time: record the laser cutting time, can be manually cleared.
Running time: record the laser running time and can be manually cleared.
7. 5 System Parameters
System parameters: maximum speed limit, plate Angle memory, motor parameters
and mouse touch screen switch parameters.
