Positioning speed
of focus-axis
Enable PWM
adjustment
mm/min
PWM adjustment
Perforated choice
Progressive enable
Types of perforation
gas
Perforation gas
pressure
Progressive time s
Perforation peak %
power
Perforation duty %
cycle
Perforation pulse Hz
frequency
focus position
mm
Perforation stay s
time
Blowing time after s
closing light
the focus axis up,
[SHIFT] + [T] controls
the focus axis down.
The speed of focus movement during
perforation process
When enabed, the real-time power
of the laser will be adjusted
according to the system speed.
The real-time power can be
adjusted in real time according to
the speed by setting the relevant
parameters, as shown in 7.2.1.
No perforation, primary perforation
Secondary perforation and tertiary
perforation
Do not close the laser and follow
the specified location at the
specified time
Nitrogen, oxygen, and air
The air pressure during
perforation, and each stage of the
perforation corresponds to one
parameter
Time from one position to another
The maximum power during
perforation, the percentage of
the peak power
The number of times the signal
goes from high to low and returns
to high per second
Proportion of the power-on time
relative to the total time within
a pulse cycle
The position of the focus in the
focus axis
Perforation time
Turn off the laser first, and then
delay it for a while to close the
