Cut touch delay
ms
Empty move touch delay ms
Follow error alarm mm
0-6000
0-6000
0-99
110
Set the alarm detection
sensitivity of the touch plate
when cutting (the capacitor is
zero at this time), the smaller
the value, the more sensitive.
Will ignore alarm when set as 0.
During the cutting process, if the
plate is touched due to the
warping of the workpiece or the
overthrust of the torch, the torch
head will automatically lift back
to the docking position and alarm.
Set the alarm detection
sensitivity of the touch plate
(the capacitor is zero at this
time) when the height controller
stops. the smaller the value is,
the more sensitive. Will ignore
alarm when set as 0. In the height
controller stop state, if the
torch head touches the plate due
to moving the X / Y axis or other
reasons, the torch head will
automatically lift back to the
docking position after the delay
time
If the difference between the
current height and the following
height in the following state is
greater than the following error
alarm, and the duration is greater
than the following error delay,
the following error alarm will be
triggered. The possible reasons:
the torch moves out the plate, the
plate jitter abnormally, etc.
that caused sudden change of
capacitance. The greater the
