and the red light is turned off after activating the laser gate, and the
red light is turned on after closing the laser gate.
[Calibration]: Move the cutting head to the calibration area by manually moving the
axis function area, select quick calibration, click the OK button in the
popup to start calibration, and establish the curve relationship between
voltage and height.
[Back to zero]: control the cutting head to return to the workpiece zero point, used
for cutting action test, the cutting head quickly back to the original cutting zero
position.
[Walking frame]: The laser activates the red light state, click the "walk frame"
function, observe the red light range of the cutting head walking frame,
Confirm that the processing area is safe. If the red light exceeds the plate,
it means that the processing plate area is not enough to cut, and the point
moving axis needs to reposition the zero point of the workpiece.
[Blowing]: applied to the test of manual blowing function.
[Focus axis up]: manually control the rise of the
focus coordinates.
[Focus axis down]: Manually control the drop of focus
coordinates.
[G]: Defined as a fixed distance move, and the
shortcut button triggers this function.
[X]: Defined as the forward function, the shortcut
keys trigger this function.
[Y]: defined as the back function, the shortcut keys
trigger this function.
[M]: Defined as the empty walk function, the shortcut
button triggers this function.
[R]: It is defined as the walk frame function, the
shortcut button triggers this function.
[I]: not defined.
[F]: defined as the switch jog / fixed distance function, the shortcut button triggers
this function..
[J]: Screen shot function.
[Clear alarm]: Clear all alarm information on the current main interface.
