Press [F]: to change the current manual move mode. It can be switched between
jog, continue and fixed length.
Press [G]: modify the distance fixed distance manual move.
Press [8]: Set the kerf value before or after cutting.
M: empty walk, empty walk along the processing track. During move, there is no torch
fall and follow, no open light, no open gas.
R: walk frame. Before processing, walk along the frame of the processing track, to ensure
that the processing pattern is in the plate area.
F9: Start cut.
F10: Pause the cut, suspending all actions in progress.
F11: Stop, can pause all ongoing action in the system.
Upper, lower, left and right 4 direction keys: move the cut torch manually when
passing the torch.
3. 1 Moving Forward
Press the [X] key in the cutting interface, and the system starts to go empty.
This process does not control any IO switch process such as laser opening and
perforation, and moves the cutting torch along the outline of the cutting figure.
Press the [F10] key to suspend.
This function is to check the cutting path, whether the code is correct, and
when the piercing process is required before cutting. To stop the empty walk, press
the "stop" button.
The forward / backward speed is set separately from the cut speed, the forward
/ backward speed can be set in the F4 parameter setting-F1 global parameter.
3. 2 Back
During processing, if you need to return along the original track due to incomplete
cutting, the following process can be performed as follows:
Press the Pause button to pause the cut.
Press the [Y] key in the cutting interface, and the cutting machine returns along
the original track. When the cutting torch retreats to the position to step back,
press the "pause" button. If it retreats too much, press [X] to advance by empty
line and then advance to the required position.
Note: The empty walk and backward function can be repeated until the cut torch
is in the ideal position.
