9. G99 ratio, rotation, and mirror image
form:
G99 Xn YnIn Jn
Parameter meaning:
X-Scale factor, 0.001 to 1000 can be set.
Y-Rotation angle, -360° to 360° can be
set.
I - X axis mirror, mirror along the X axis, 1 means mirror, 0
means no mirror
J - Y axis mirror, mirror along the Y axis, 1 means mirror, 0
means no mirror
Note:
For a code, there can be either a G99 or no G99. If there is a G99, the following
parameters X, Y, I, and J cannot be omitted.
Both the mirror image and the rotation take the origin of the Cartesian
coordinates (0,0) as the reference point.
10. G04 time delay
form:
G04 Pn Parameter meaning:
P delay time, the following parameter is 0.01 seconds, such as P100 means the
delay of 1 second.
11. Programming considerations
The programming must contain G92 (reference point setting) and M02 (End of program)
instructions.
G41 / G42 and G40 must be paired and used. If G41 / G42 is omitted, the default is zero; if
G40 is omitted, the default is valid.
G00, G01, G02, G03 can be abbreviated as: G0, G1, G2, G3.
Continuous G00 (or G01, G02, G03), G 00 (or G01, G02, G03) can be omitted.
1 3.4 M code description
M07
M08
M11
M12
M09
Table 1 3.6 Common M codes
No parameters
Perforated
fixation cycle
No parameters
End cutting fixation
cycle
No parameters
Establish spray
powder offset
No parameters
Cancel the spray
powder offset
No parameters
Open the spray
powder
