[Z↑PgUp]: in the code interface,it is page up key, in the
other interface,it is the torch up key.
[Z↓PgDn]: in the code interface, it is page down key, in
other interfaces, it is torch down key.
[HOME]: In the code interface, it is jump to the first line, in other interfaces,
it is to increase the speed of the rotation axis.
[END]: In the code interface, it is jump to the last line, the other interface is
to reduce the speed of the rotation axis.
[▲]......[▼]: Four-direction keys. The X and Y axis movement can be controlled on
the main interface.
[1]: Number 1.
[ ] The hand-shaped key in the middle of the direction keys is the ALT key,
similar to the [F] key, which can switch jog mode.
[▷]: START key to start the cutting. Is also known as the [Start] [F9] key.
[‖]: suspend key, pause the cut, [pause] [F10] key.
[‖]: STOP key, stop the cutting. Also called [stop].
[G], [X], [Y], [I], [R], [J], [F], [M]: are commonly used letter keys. At the same
time, it has the reuse function, which can be used as a special function key. Under
the main interface, the letter in front of the parameter item on the screen is the
shortcut key prompt, which can be used for shortcut operation.
[1] - [9]: The number key. Number keys are configured with different shortcut buttons,
and these keys can be customized to configure some functions. For example, in the
stop state, the switch of the optical switch can be controlled by pressing [1],
the blowing can be manually turned on / off by pressing [2], and the pressing [5]
can be adjusted back to zero.
[↑]: Yellow shift key, press this key and the number key at the same time, equivalent to the
yellow letter on the number key. For example, press this key and [7], equivalent to character
A.
[↑]: Red shift key, press both this key and the number key at the same time, equivalent to
the red letter on the number key. For example, press the key and [7], equivalent to character
N.
[ESC]: Cancel key, also known as the back.
[←]: Hold down the yellow key to achieve the space bar effect.
[Tab]: User focus switch, (find boundary value)
[Del]: Delete.
110
