[↑]: Yellow shift key, press this key and the number key at the same time, equivalent
to the yellow letter on the number key. For example, press this key and [7], equivalent
to character A.
[↑]: Red shift key, press both this key and the number key at the same time, equivalent
to the red letter on the number key. For example, press this key and [7], equivalent
to character N.
[←]: Hold down the yellow ↑ key and ← to input space.
[ESC]: Cancel, also called exit key.
[Del]: Delete.
[Enter]: Confirm.
2.3 Description of the system main interface
The contents displayed under the main interface are described as follows:
① Displays the controller model and version number.
② Shows the current processing speed. The G code currently being processed,
showing the current line and the next row.
③ Display cut file name.
④ Show the status of the cut. It can be run, manual, pause, stop, etc.
⑤ Display the perforation information: perforation number, line number, drilling
number, etc.
⑥ Displays the cutting trace of the current processed workpiece. The actual outline
of the workpiece is displayed simultaneously with the contour with kerf. (The green
line is the actual outline of the cutting piece, and the blue line is the cutting
trace with kerf. When cutting, the center of the torch will cut along the blue line.)
⑦ Custom monitor window. Display the value of common items, display real-time
running data, convenient to view the running state. Can configure G code display,
graphics size information, artifact coordinates and mechanical coordinate
information, real-time speed, etc.
⑧ Function menu, displays the name of [F1]...... [F8] function key. Displays
different function names under different operation interfaces.
⑨ Watch window. Show the IO status. The signal light is a green "●" light,
indicating that the signal is valid or occurring; A red lamp "●" indicates that
the signal is invalid or did not occur. For example, when pressing the [follow]
button, the follow indicator on the screen turns green,
Send a follow instruction to the height controller, press the [follow] key again,
and the indicator light turns red to stop the following action.
