parameter
unit
Speed planning and speed
limit mode
Enable small arc speed limit
Small line segments fit
Precision of small segment mm
fitting
Arc radius tolerance
mm
The center of the circle %
corrects the tolerance
remarks
Two modes can be set up to
facilitate switching when cutting
different plates.
After checking, the system will
automatically slow down when cutting
the small circle and arc.
Yes / no
The error range of the smooth
transition of the small segment (the
minimum length of the small segment in
the G code, and the G code below that
length is merged into a line of G code)
The error range of the arc instruction in the G
code, the error is not allowed to exceed this
parameter.
11 . 4.5 Network configuration
IP address settings
Click the "Network Configuration" button in the [F5 diagnosis] -> [F8 system
definition] -> [F4 machine tool] to open the pop-up interface of the "Network
Configuration" button and set the IP address.
Figure 11.9, the network configuration
