primitives are two-dimensional graphics, the mirroring operations of
the primitives are determined relative to a straight line. Two points
to determine a line, now click the left mouse button to complete the
first point position setting, then there will be a line segment
connected to the mouse from the first point, and a new image after
mirroring according to this line segment. Mirror processing is based
on this line segment, moving the mouse, you can change the angle and
length of the line segment, and then the graphics after the mirror
will change in the process of moving. After getting the desired
graphic, click the left mouse button again, and the dialog box shown
in Figure 6.1-7 will pop up:
Figure6.1-7
In the left selection, you can choose whether to delete the
original image.[Delete original]Indicates that the original image is
deleted, and the original image is deleted, that is, only the image
after the image is retained.[Keep origianl] Indicates that the
original image is retained, and the two primitives before and after
the image are retained.
