number symbol next to the mouse. The starting number is 1, then click
on the element you want to process the first. At this point, the
workpiece becomes the first workpiece to be machined, and the number
in the circle next to the mouse will change to 2. At this point,
click on the next element to be processed. The processing order of
the element is the second one. By analogy, the ordering of all
primitive processing sequences can be completed. During the
reordering process, the software will automatically plan the
machining path according to the rules set by the user, and indicate
the machining empty travel with white lines.
Click [Start Point Selection] in the processing selection column.
, You can customize the workpiece from that point to meet the
needs of more situations.
After selecting the workpiece, click [Compensation] in the
processing selection column. , It can set the expansion and
contraction and perform tool compensation. Set the frame as shown in
Figure 5.1.3-1:
Figure 5.1.3-1 Offset setting
