Chapter Four Commissioning Process
Ensure that the control board is connected to all the signal
lines such as the driver, inverter, in-position signal, and output
signal. Doing a good job of debugging can ensure safe, stable and
efficient work.
The debugging process includes axis parameter setting, machine
movement range setting, spindle setting, tool magazine setting,
vibrating knife zero setting, lens setting.
4.1 Axis parameter setting
After opening the software, first move each axis separately in
low speed mode, and do this in the machine control bar. Click
,
The nose will move to the X axis; Click
, The nose will move
negatively towards the X axis. The remaining axes are the same here.
观 Check whether the movement direction of the machine head is
the same as the operation. If the actual movement direction of the
axis is opposite to the control direction, open the parameter page
and click [Manufacturer Parameter].
View the
manufacturer parameters, click on the right axis parameter
classification，Find the corresponding [Axis Direction] parameter of
the opposite axis of motion and change the parameters. If the current
parameter is 1, the motion is reversed, then change this parameter to
-1.
Set the pulse equivalent of each axis. If the parameter is wrong,
the size will not match the file size during processing. Please make
sure the parameters are correct.
