file is located, and double-click the file to load the file. You can
view and edit the file in the program window as shown in Figure 6.1-
2:
Figure 6.1-2
After processing, if you need to replace the G code file, you can
click [G code file loading]
Overwrite the loaded file,
click [Load File] at the bottom of the program window.
,
Can also achieve this effect.
When you need to make a simple edit of the G code file, you can
click [Edit]
, The editing interface pops up and is edited
in this window. Please pay attention to save after editing.
[G code file uninstall]
Can uninstall the currently
loaded NC file, click this button to uninstall, or click [Uninstall
File] at the bottom of the program window.
achieve the purpose of unloading files.
, Can also
6.1.1.2 Image format file opens
[Image open]
The option is to open the image format
file. Common include JPG, DIF files. The user can directly open the
modified type file, and then click [image open]
, The
file selection dialog will pop up, find the image format file we need
