You can view the G code on the [G Code] screen under the
[Program] page. If you need to edit the file, click [Edit File].
, Ability to edit files in the pop-up action box.
5.3.4 Set the workpiece origin
Set the workpiece origin according to the G code file and tool
the tool to the material surface or the material bottom surface. On
the [Manual] page, manually move the X and Y axes to the target
position. Click [X, Y to clear] , Complete the workpiece origin X
and Y axis coordinate settings. Manually move the Z axis to perform
the tool setting. After reducing the workpiece origin coordinate,
click [Z Clear].
Complete the workpiece origin setting. If the
machine has an automatic tool setting tool, use the automatic tool
setting. For details, please refer to 6.4.3.
The user can select the workpiece origin autonomously and select
it on the [Workpiece Coordinates] screen under the [Coordinate
System] page. 6 groups of 60 for users to choose to use.
5.3.5 Processing control
The CNC-Couter control system can view the position information
of each axis and perform simple control during machining. The control
interface is shown in Figure 5.2.5-1:
