spindle speed control mode, Select the control mode corresponding to
the machine.
Match the maximum speed of the software with the inverter. If the
maximum speed of the inverter parameter setting is 36000R/Min, the
software parameters 20001 spindle maximum speedAlso set to
36000R/Min.
Multi-speed mode: The machine frequency converter is designed to
control at multiple speeds, Spindle speed control mode The parameter
is set to 2, parameter 20010-20017 The Xth speed，The setting should
be completely the same as the speed of the inverter, otherwise the
actual speed will be inconsistent with the specified speed, which
will affect the machining effect.
Analog mode: The machine frequency converter is designed to
control the analog quantity, Spindle speed control mode The parameter
is set to 1, parameter 2006 analog minimum voltage value and 20007
analog maximum voltage value, Set the same parameters in the
inverter to ensure that the specified speed is consistent with the
actual speed.
4.4 Tool magazine setting
This system supports the machine tool loading tool magazine.
Before using the tool change function, the tool magazine position
setting and tool setting position setting are required.
First, set the tool setting position, move the spindle to the top
of the tool setting tool. On the [Tooling] page under the [Coordinate
System] page, click [Load Current X-axis Coordinate] in the [Tool
Setting] column.
In [Load current Y-
axis coordinates]
，At this point,
