Figure5.3.5-2
To move the X and Y axes, the user needs to point the camera at
the Mark point in the lower left corner of the processing file (the
system defaults to the lower left corner, the user can adjust
according to the requirements), and move the camera position so that
the Mark point appears in the display window. Click on the bottom
right corner of the page [CCD Processing]
, At this
point, the system starts automatic patrol positioning, and starts
processing after positioning is completed.
The appeal method uses the Mark point identification template as
the system's own template. The CNC-Router system provides users with
autonomous template addition function, and users can add templates
themselves to increase adaptability. Click [Template Add]
The template add operation page will appear, and
the template will be selected. The template can then be framed. The
template setting interface awakens the shape selection and name
setting, and can set the gray value and the precision value as
needed.
