location. The line length and reference point can be set at the top.
As shown in Figure 6.1-15:
Click [vertical line], With a vertical line drawing operation,
the mouse will change to a cross. Ability to preview the rendering
effect and click the mouse to confirm placement in that location.
Same as horizontal line drawing, you can set the length of the line
segment and the reference point above.
6.1.3.2 Arc
Click [Arc]
The arc drawing mode selection box
will pop up, including [two points and radius] and [three points].
Click [two points and radius]
With two
points and a radius for the arc, the mouse will change to a cross.
The radius and direction of the arc can be set at the top of the
drawing. After the arc radius is set, the mouse moves to the target
point and clicks. This point is the starting point of the arc. Move
the mouse, the arc will rotate, click to confirm the second point.
Click [three points]
Perform a three-point
arc operation and the mouse will change to a cross. Click the mouse
to determine the starting point of the arc. The second click
determines the middle point through which the arc passes, and the
third click confirms the end point of the arc. During the drawing
process, move the mouse to preview the drawing result, and then use
the left mouse button to place the user's needs.
6.1.3.3 Circle
Click [circle]
When you draw a circle, the
mouse will change to a cross. At this time, the center coordinates
