The removal threshold can be filled in. The distance between the
endpoints of the two segments is less than the value. During the
loading process, the second two lines are connected.
[Automatic expansion]: When the file is loaded, the elements in
the file are expanded, and the user does not need to perform manual
expansion again. Enable this function by checking the box. The
external expansion data can be filled in, and the external expansion
distance will be the data.
[Picture Format DPI]: This column fills in the DPI value of the
graphic file. Open the file attribute box to view it. You need to
fill in the correct DPI parameter value to make the loaded file size
normal. Ensure that the processing is carried out normally.
[Whether the image format file retains the internal line]: When
the image file is loaded, the graphic internal line will also be
recognized, and the user selects whether to keep it according to the
demand.
[Whether CCD processing]: The user selects according to the
processing requirements. When CCD patrol processing is required,
please check it. Otherwise, the patrol positioning will not be
performed during the processing.
[Sorting Strategy]: This strategy is used to sort the selected
processing elements, and the user can choose how to sort according to
their own needs. Click on the desired sorting method.
[Forward mode]: Select the starting position of the next line of
elements after processing one line of primitives. The Z type always
starts processing from the first direction set by the user; the snake
type indicates starting from the lower element of the last element of
the line. Processing the next line of workpieces。
