After the change is complete, restart the software. The
parameters take effect. The axis parameters are set.
4.2 Machine movement range setting
According to the position limit switch of the machine tool,
select the zero return direction of the mechanical zero return. The
zero return direction of each axis needs to be set separately. After
confirming the zero return direction, change the [rough positioning
direction] parameter and set the zero return direction. The same as
the positive direction of the axis is the positive direction.
Switch the interface to the diagnostic interface and trigger the
limit switch to ensure that each axis limit signal can be triggered
normally. Click [All Zero] in the [Action] menu bar. The machine
starts to return to zero.
Wait for the zero return to complete, manually move each axis to
the maximum value of the forward and negative travel, and record. The
software limits the machine movement stroke by limiting the upper and
lower limits of the axis motion, and fills the mechanical coordinates
of the recorded maximum stroke into the [stroke upper limit] and
[stroke lower limit] parameters respectively. When the machine is
equipped with a tool magazine, please make sure that the tool
magazine is within the stroke range, otherwise the tool change
operation will not be completed. After setting the parameters,
complete the machine movement range setting.
4.3 Spindle setting
The system supports multi-speed and analog two spindle speed
control modes. Change parameters according to machine design 20008
