To move the X and Y axes, the user needs to point the camera at
the Mark point in the lower left corner of the processing file (the
system defaults to the lower left corner, the user can adjust
according to the requirements), and move the camera position so that
the Mark point appears in the display window. Click on the bottom
right corner of the page [CCD Processing]
, At this point,
the system starts automatic patrol positioning, and starts processing
after positioning is completed.
The appeal method uses the Mark point identification template as
the system's own template. The CNC-Router system provides users with
autonomous template addition function, and users can add templates
themselves to increase adaptability. Click [Select Template]
The template add operation page will appear, and
the template will be selected. The template can then be framed. The
template setting interface awakens the shape selection and name
setting, and can set the gray value and the precision value as
needed.
Then test, click [test]
,Perform a template test. Check
to see if the camera can find Mark points based on the template we
selected. If you can find the Mark point to indicate that the
template is available, click [Save]
, Save the template
for direct use in the next processing.
After the first processing, the software will automatically
record the first Mark point position as the recognition starting
point. If the processing material position has not moved, the user
can click [Move Start Point].
Quickly return
