5.1.1 Back to mechanical zero
To return to the mechanical zero point, you need to set the axis
direction, pulse equivalent and coarse positioning direction first.
Refer to 6.1 axis parameters for details.
Open the software, open the [Operation] column of the software
menu bar, and then click [All Zeros], the machine starts the
mechanical zero return action, waiting for the zero return. After
confirming that the machine origin is successful, the mechanical zero
return completion flag will appear in the front axle return status
bar of the corresponding axis .
When the user ensures that the mechanical coordinate of the
current position is consistent with the actual machine coordinate of
the machine tool, for example, the machine tool has not been closed,
and no abnormal situation such as sudden stop occurs, click [Direct
Settings] of [Operation] in the menu bar to directly use the current
Mechanical coordinate system. When this operation is completed, the
mechanical zero return status flag will also appear on the machine
control bar mechanical zero return status bar .
5.1.2 Importing files
The CNC_Couter system supports image editing and can import .JPG
and .TIF files directly. After importing the file, the software will
automatically extract the outline of the graphic and display it in
the display interface.
Click [File] on the menu bar , Click [Image Open] in the pop-
up dialog box.
. After that, the file selection interface
will pop up, open the folder location of the file, double-click the
