4.6 Camera settings
成都兴多维科技有限公司
Chengdu multidimensional robotization technology company
If the machine supports the CCD positioning function, the camera
will be mounted next to the spindle. First adjust the camera exposure
and focus. The observation lens reveals two adjustable rings, the
upper ring is used to adjust the lens exposure, that is, the
brightness of the picture is adjusted; the lower lens is used to
adjust the lens focal length, that is, to adjust the picture clarity.
First adjust the exposure, the camera itself can automatically
set the exposure, so you only need to set the approximate exposure,
try to increase the lens exposure, so that the picture displayed
during the movement will be more consistent. Rotate the adjustment
ring, wait for the camera to automatically set the exposure, observe
the software camera display window, and the brightness is moderate.
Tighten the screws to lock the adjustment ring.
After the exposure adjustment is completed, set the focus. Place
a piece of paper under the camera, adjust the ring below the lens and
view the software image display window to adjust the lens focal
length to the clearest point. Tighten the screws to lock the
adjustment ring. Complete the lens adjustment.
Check the software camera page display window to see if the image
is upright. If the image display is rotated, adjust the rotation
angle under Camera Settings. After rotating the erect, check whether
the image needs horizontal or vertical mirroring, and check the
corresponding options below to set the screen. Complete camera
settings。
