#20030 The rear fill-in number is the X-direction width of the
first Mark point, which is the X-axis width of the Mark point in the
print file. The remaining Mark points have the same X width;
#20030 The rear fill-in number is the X-direction width of the
first Mark point, which is the X-axis width of the Mark point in the
print file. The remaining Mark points have the same X width;
#20031 The trailing number is the width of the first Mark point
in the Y direction. This value is the Mark point Y-axis width in the
print file. The remaining Y points of the Mark point are the same;
The FUNC "CCD" change code is the CCD patrol start code. You need
to add this code software to perform the patrol action.
The spindle start command in the M03 G code, the spindle will be
rotated if the command is added, otherwise the spindle will not open
for machining, causing the cutter to be broken.
After adding the header of the appeal file, the file is set and
the file is ready for processing.
In the menu bar [File] click [G code file loading]. The Windows
file selection dialog will pop up, find the path to save the G code
file, open the file to complete the loading.
[Load file] at the bottom of the program interface
, It
is also possible to perform a file loading operation, and the
subsequent operations are the same as above.
After the file is processed, if you do not need to perform
secondary processing, click [G code file unload] in the menu bar
[File]. Will uninstall the currently loaded file.
