5.3 G code file processing
Back to
mechanical zero
Importing files
Check file
Set the
workpiece origin
Processing
control
5.3.1 Back to mechanical zero
To return to the mechanical zero point, you need to set the axis
direction, pulse equivalent and coarse positioning direction first.
For details, refer to 6.1 axis parameters.
Open the software, open the [Operation] column of the software
menu bar, and then click the machine [all zeros], the machine starts
mechanical zero return, waiting for the zero return. After confirming
that the machine origin is successful, the mechanical zero return
completion flag will appear in the front axle return status bar of
the corresponding axis. .
When the user guarantees that the mechanical coordinate of the
current position is consistent with the actual machine coordinate of
the machine tool, for example, the machine tool has not been closed,
and no abnormal situation such as sudden stop occurs, click [Direct
Settings] in [Operation] in the menu bar to directly use Current
mechanical coordinate system. When this operation is completed, the
mechanical zero return status flag will also appear on the machine
control bar mechanical zero return status bar. .
When the vibrating knife is used, it is necessary to ensure that
the direction of the vibrating knife blade is in the same direction
