[sort]：When the machining graphics are selected, the software
that needs to be processed is automatically sorted. If the user needs
to modify the processing order, you can click [Sort] The open
function modifies the machining sequence. Click to start sorting, the
user clicks the graph in order of processing to complete the sorting.
During the sorting process, you can view the serial number of this
time next to the mouse. Users can exit the sort in the middle.
[Processing start point]: The software will automatically define
the machining starting point when the machining file is selected, and
the user can customize the machining starting point according to the
requirements. Select the graph and click [Start Point Settings]
Use this function to select a point to start the graph. Setup
completed.
[External expansion and contraction]: Select the graphics to
expand and shrink the graphics. See 5.1.2.17 [Extended Expansion].
Edit: Simple editing of the elements, mirror rotation, etc.
[Horizontal Mirror] and [Vertical Mirror]: Mirror the selected
primitives. The axisymmetric line is the centerline of the primitive.
After mirroring, the location of the primitive is not changed.
[Rotate]: Rotate the selected element to the reference point in
the center of the element. The rotation angle provided by this
shortcut is three common angles of 90, 180, and 270, and the position
after rotation does not change. If you need a more advanced rotation,
you can use the rotation in the menu bar to select a more appropriate
angle.
