5.4 Vibrating knife processing
成都兴多维科技有限公司
Chengdu multidimensional robotization technology company
CNC-Router software supports machine tool mounting vibration
cutting equipment for cutting soft materials. Same as when using
spindle cutting, choose whether to use CCD correction function
according to your needs.
Back to
mechanical zero
Importing files
Check and edit
files
Process setting
Turn on the
camera and set
Processing
control
5.4.1 Back to mechanical zero
To return to the mechanical zero point, you need to set the axis
direction, pulse equivalent and coarse positioning direction first.
Refer to 6.1 axis parameters for details.
Open the software, open the [Operation] column of the software
menu bar, and then click the machine [all zeros], the machine starts
mechanical zero return, waiting for the zero return. After confirming
that the machine origin is successful, the mechanical zero return
completion flag will appear in the front axle return status bar of
the corresponding axis. .
When the user guarantees that the mechanical coordinate of the
current position is consistent with the actual machine coordinate of
the machine tool, for example, the machine tool has not been closed,
and no abnormal situation such as sudden stop occurs, click [Direct
Settings] in [Operation] in the menu bar to directly use Current
mechanical coordinate system. When this operation is completed, the
