mechanical zero return status flag will also appear on the machine
control bar mechanical zero return status bar. .
5.4.2 Importing files
The CNC_Couter system supports image editing and can import .JPG
and .TIF files directly. After importing the file, the software will
automatically extract the outline of the graphic and display it in
the display interface.
Click [File] on the menu bar. , Click [Image Format Open] in
the pop-up dialog box.
. After that, the file selection
interface will pop up, open the folder location of the file, double-
click the file, and the software automatically recognizes the graphic
outline, that is, the processing path, and projects it in the display
window.
In addition to being able to import JPG files, users can also
open edited files to improve productivity. Click [Open]
A dialog box pops up and selects a
folder. Select the file that was edited and saved in the past, and
the content of the file will be displayed in the window, and the user
will adjust it and then process it.
If the user has generated contours, the exported file is in DXF
or PLT format. You can use DXF or PLT format files for processing.
Click [Open DXF/AI/PLT] in the [File] menu bar to open this type of
file. The file can be displayed in the software by opening the file
in the pop-up dialog box, and the user can edit and process the file.
