Combination Key
+
Function
Breakpoint resume
CAUTION
1) Please note that the combination key in the above two tables are ones by default.
2) Pressing combination key “Shift+Menu” can open help information page of combination key.
8.2.2. Tool Change Parameters
You can find “Tool Change” under “Oper Param”. See 8.1.2 for reference.
8.2.3. Clamp/Unclamp Tool Manually
For NK105G3 CNC system, you can press
IV-
+
1 to execute the tool unclamp
command when manually changing a tool as needed in some special situations. At this time, the LED
beside the terminal GY18 on the control box becomes light. After manually changing the tool, you need
to press
IV-
+
1 to execute the tool clamp command, the LED beside the terminal GY18 on
the control box turning off.
For NK105G2 CNC system,
+
is the combination key to manually clamp/unclamp
tool.
8.2.4. Process of Linear Tool Change
「78」Cylinder ATC and Linear ATC Function
    "
