CAUTION
LED diagnosis is only available in NK105G3.
6.8.1. System Info
In this page, you can view the software version, control card No., remaining time and registered
times. If an item is wrong, after pressing [OK] for confirmation, an error prompt “Failed to Read
Registration Info” will be displayed. At the same time, the other items cannot be read, either.
6.8.2. Ports List
For details, see Chapter 5.3.
6.8.3. Keypress Diag
This menu item is used to check whether panel keys work normally. After entering the test page,
the system will display a prompt “Press a key”. Pressing any key at this time will show the name of the
pressed key on the screen, as shown in Fig. 6-21. If the pressed key is damaged and out of work, the
screen will not display its name or the wrong key name. Pressing “ESC” will exit from this page.
Current key:
Up
6.8.4. Inport Diag
Fig. 6-21 Keypress diagnosis page
This page is only for viewing the polarities of the input ports, instead of changing them.
6.8.5. Outport Diag
This page is only for viewing the polarities of the output ports displayed by running lights, instead
of changing them. The corresponding relation among system output terminal No., terminal board ports
and signals is listed in Chapter 5.3 Port Polarity.
6.8.6. LED Diag
This page is only for checking the work conditions of the LEDs on the NK105G3 handheld box.
In the LED diagnosis page, press F1. If the LEDs work regularly, all the LEDs become light.
Menu Page「61」
    "
