10.1.5. Parameter Setting of PANASONIC MINAS_A4 Servo
Driver
Para.
No.
Function
Value
Pr01 LED initial status 12
Select
Pr02
mode
control
0
Select command
Pr40
1
pulse input
Description
Monitor if the number of sent and received pulse is
correct by setting this parameter. In Weihong control
system, the correct quantity of pulse sent by control
card is detected by pulse inspection in order to
determine whether there is electrical interference.
0: position mode
1: velocity mode
2: torque mode
1: input through difference exclusive circuit
Select command
Pr42
3
pulse input mode
Set command pulse input mode: command pulse +
command direction, negative logic
Pr48
Pr4B
The 1st numerator
of the command
pulse frequency
multiplication
Denominator of
the
command
pulse frequency
multiplication
Need
calculation
Range:
1～10000
Need
calculation
Range:
1～10000
Typical values: pitch 5 mm, encoder resolution 10000,
deceleration ratio 1:1, pulse equivalent 0.001 mm:
Pr48=10000
Pr4B= pitch 5mm/ pulse equivalent 0.001mm=5000
So, Pr48/Pr4B=10000/5000=2/1
After the parameters are set, writing mode of EEPROM has to be selected. Please refer to the
following steps:
1) Press [MODE] button → Select [EEPROM]→ Enter mode [EE_SET];
2) Press SET button, showing [EEP ―];
3) Keep pressing UP direction key for approx. 3 seconds, then [EEP ――] will be displayed, and
then writing starts until [Start] is displayed.
If [Finish] is displayed after saving the parameters, it means successful modification. If [Reset] is
shown, alteration will be validated only after restarting the driver. If [Error] occurs, the write-in is a
failure, and another setting is needed.
