5.8.6. Hard Limit Handling
The system detects hard limit periodically under the main page. When hard limit occurs, its prompt
dialog is as shown in Fig. 5-17.
Limit! Exit
Manually.
OK
ESC
Fig. 5-17 Hard limit dialog
At this time, press [OK] to return to the main page under “Jog” mode, with “Limit Rls.” displayed at
the bottom right corner of the LCD, as shown in Fig. 5-18. Or you can press [ESC] to directly back to
the main page under “Jog” mode.
1X
15.617 Idle
1Y
551.107 SOff
1Z
9.900 Slow
Jog
Limit Rls.
Fig. 5-18 Prompt interface of limit release
Move the machine tool away from the limit position, “Limit Rls.” disappearing. The main page
returns to its normal state.
