Method two takes advantages of tool measurement. Press
+
0 to execute moveable
tool measurement. After measurement completed, the coordinate of Z axis is Z workpiece origin.
5.7.4. Start Machining
Press the start key
to start automatic machining in the machining page.
Prompts like feedrate override and feed rate are scrolled on the LCD during file machining.
In addition, during auto processing, pressing the [OK] in the main page will display machining info,
including loaded program name, processing line number, total line number and elapsed processing
time.
5.8. Adjustment during Automatic Machining
5.8.1. Feedrate Override Adjustment
Feedrate override can be increased or decreased through
or
during machining.
The feed rate changes with the feedrate override. Their relationship is as follows:
Actual feed rate = Feed rate × Feedrate override
The least unit of feedrate override is 0.1. Namely, override increases (decreases) by 0.1 after
each press of
or
; at the same time, the feedrate override displayed on the LCD
increases (decreases) by 10%. The range of feedrate override is within 0%~120%. In addition, the
display of feed rate value changes with the feedrate override.
5.8.2. Spindle Speed Adjustment
Spindle speed are adjusted by pressing
+
or
+
, and divided into 8
gears from S0~S7 with speed increasing sequentially.
5.8.3. Machining Pause and Jiggle
If machining is found not in position exactly, suspend the machining and then execute manual
jiggle. Jiggle is only effective in pause status of auto mode. Suspend machining by pressing the
“Pause” key in machining, “Paus” displayed at the top right corner of the LCD while the machine tool
stopping moving; as for the spindle, whether it stops or not is decided by the setting of the parameter
Machine Tool Debugging「35」
    "
