1. Summarization
1.1. System Introduction
Independently-developed NK105G2/G3 provides a whole set of solutions to engraving machines
based on embedded industrial control platform.
NK105G2/G3 integrated CNC system is composed of a host system and an operation panel. Also
called control box, the host system integrates system control card, terminal board and other parts, and
makes connection with the operation panel via a 15-pin extension cable.
The up and down ends at the back of the control box are used to inlay terminals while the left side
includes an USB interface and a DB15 interface. The DB15 interface is for connection with the
operation panel, while the USB interface for external connection with USB equipment (e.g. USB flash
drive).
Also called handheld box, the operation panel is concise and portable, connected with the host
system via a 15-pin extension cable, so it can break away from the distribution box and facilitate
machine tool control. And its moving distance is only restricted by the length of extension cable.
1.2. Basic Configuration
Basic configuration of NK105G2 system:
NK105G2 handheld box
NK105 three axes control box
Basic configuration of NK105G3 system:
NK105G3 handheld box
NK105 three axes control box
1.3. Mechanical Dimension
The integral thickness of NK105 host system is 218.3mm, with terminals embedded at its up and
down ends. Fig. 1-1 is the dimensional drawing and cut-out drawing of NK105G2/G3 control box (unit:
mm).
