CAUTION
If you can ensure that the axis position will not deviate after E-stop, you can set the parameter “Sign of BK
REF” to “No”, so you can continue machining without backing to machine origin after E-stop is obviated.
Otherwise, you need to set this parameter to “Yes” to ensure machining accuracy.
Spindle Parameters
Parameter
Spindle Set
Spindle Gears
ON/OFF Delay
Initial Gear
Max. Spdl Speed
Meaning
Setting range
Spindle speed is divided into several gears.
The wait time for the spindle to reach normal rotary
speed or stop completely after turned ON or OFF
Initial speed gear
Max. spindle speed
1~8
0~60000 ms
1~[Spindle Gears]
Spindle speed~999999
mm/min
Y Rotary axis
Parameter
Y AsRotaryAxis
Rotary Y Pulse
mm As Unit
Rev. WorkRadius
Rotary Takeoff
Rotary Y Acc.
Max. RotaryVel.
Meaning
Setting range
Whether Y axis is set as rotary axis
Yes: Valid; No: Invalid
The pulse equivalent of Y axis when it is set as
0~100 mm/p
rotary axis
It sets the measure unit for the rotary axis.
Yes: in mm
No: in deg
The length of Y axis in CAM programming is the
value of workpiece radius × 2× π. The value of this 0~1000000mm
parameter changes with the radius of workpiece.
The takeoff speed of the rotary axis
0~1000000 mm/s
The acceleration of the rotary axis, with unit as
rad/s2
0.001~100000.0 rad/ s2
Max. rotary speed
0.06~6000000 r/min
Lubrication Setting
Parameter
Lube
EnableAutoLube
Time Interval
Duration
Meaning
Setting range
Whether to open lubrication pump automatically at
fixed period
Time interval between two adjacent lubes
Duration time to release lubrication oil each time
Yes: Valid
No: Invalid
0~34560000 s
0~34560000 s
