1. Park Mode
2. Park Site
Specialized Concentrated Focused
Fig. 5-7 Park MCS site interface
Select “Park Mode”, and then press [OK] to enter the interface as shown below.
Not move
To park site
To WCS Origin
[OK] Select
Fig. 5-8 Park mode selection
Press the “Up” or “Down” key to select the desired item, and then press the [OK] to accomplish
the selection and return to the previous page. If “To park site” is selected and confirmed, input or select
the park site under “2. Park Site”.
After selecting “Select Site”, press the [OK], and then press [OK] again to set current position as
the park position. The system will then back to the main page automatically. At this time, you can press
the “Start” key to start machining directly.
CAUTION
Current position cannot be set under “Select Site”; you need to set the current position of the spindle in advance.
5.5.3. Spindle Stop
Press the “Menu” key→ 4. Oper Param→ 10. SpindleStop, and then press the [OK] to enter the
setting interface of “Spindle Stop”, in which press the “Up” or “Down” key to select the corresponding
parameter for modification. See Fig. 5-9 for the three modes of spindle stop.
1. SOff at Pause
Yes
2. SOff at Stop
3. SOff at End
Fig. 5-9 Spindle stop setting interface
5.6. Manual Machining
Manual machining refers to manipulating a machine tool by the direction keys of the three axes on
the panel. At the same time, the operation speed and step length, etc. can also be adjusted according
「30」Machine Tool Debugging
    "
