Preface
About This Manual
This manual is intended for machine tool builders and users. If you use the CNC system for the
first time, you need to read through the manual. If you are experienced with the system, you can
search for the desired information via the contents.
With 11 chapters, this manual can be divided into 5 parts, as follows:
1) Part 1: preface, introducing the precautions about transportation and storage, installation,
wiring, debugging, usage, and so on. You need to read them carefully beforehand to ensure
safe operations.
2) Part 2: introduction to hardware used together with the system, including Chapter 1&2&4.
Chapter 1 introduces basic configuration or the components of the system and the
mechanical dimension. Chapter 2 introduces terminal pin signals and wiring of NK105 three
axes control box. Chapter 4 lists all keys on NK105G2 and NK105G3 operation panels,
introducing functions of single key and key combinations.
3) Part 3: software operation, including Chapter 5&6&9. It focuses on how to use the system in
real machining, taking NK105G2 as an example. Specifically, Chapter 5 comprehensively
introduces machining steps from the perspective of machine debugging; Chapter 6
introduces menu pages and menu items of the system; Chapter 9 introduces update
operations of the system.
4) Part 4: Chapter 7~8, specially introduces operations of NK105G3 and separate software with
cylinder ATC function and linear ATC function.
5) Part 5: Chapter 10~11. Chapter 10 gives the parameter settings of drivers of varied brands as
well as their wiring diagram with the NK105 system. Chapter 11 is software license
agreement.
Applicable Product Models
This manual is applicable to NK105 G2/G3 CNC system. Refer to the table below for details:
Product Model
Remarks
NK105 G2/G3 CNC System Herein referred to NK105G2/G3 as abbreviation.
Contact Us
You can contact us by the following info for technical support and pre-sales/after-sales service:
Company Name:
Weihong Electronic Technology Co., Ltd.
Headquarters Address: No. 1590, Huhang Rd., Fengxian, Shanghai, PRC 201400
Tel:
+86-21-33587550
Fax:
+86-21-33587519
Website:
www.weihong.com.cn/en
Preface「I」
