4) Call of a sub-program in the PUBLIC is not allowed in the tool path file.
6.3.8. Origin List
Press “Menu”→ 3. Operations→ 8. Origin List, and then press [OK] to enter the origin list page. To
save workpiece origin, the operation steps are as follows:
If the current position is desired to save as workpiece origin, press the corresponding shortcut key
to set it as workpiece origin→ turn to the origin list page→ move the cursor to one of the 8 items and
press “OK”→ press the number key “1” to save the current position as workpiece origin.
CAUTION
1) Before saving, loading or deleting workpiece origin in the origin list page, press “OK” to confirm the
selected item.
2) The number key 1 is for saving workpiece origin, 2 for loading, and 3 for deleting. If workpiece origin
saved in one of the 8 items is loaded, it will be set as the current workpiece origin.
6.3.9. Nearby Process
NK105G2/G3 supports machining from proximal point. In case of insufficient machining, you can
manually move the spindle nearby, and then execute “Nearby Process” to resume machining from the
machining point nearest to the current spindle position.
6.4. Oper Param (Operator Parameters)
Parameters Related with Velocity
Parameter
Meaning
Setting range
Related with the
G00 Speed
specific machine tool
G00 speed, which can be set in this parameter or in
G00 speed < Max.
the program file
velocity of machine
tool
Gxx Speed
Gxx speed
Related with the
specific machine tool
The max. velocity of a machine tool is related with the setting of pulse equivalent. For the detailed
expression, see Chapter 5.1.2. The relation between actual feed rate and feedrate override is:
Actual feed rate= Feed rate × Feedrate override
Jog speed and rapid jog speed are set in the manual speed setup page; G00 speed ≥ machining
speed, and rapid jog speed ≥ jog speed > 0.06
