7.2. Automatic Machining
Automatic machining refers to that the system processes system files and the files in the USB
flash drive in terms of instructions, also called file machining. All the parameters of machine tool and
system should be set correctly before automatic machining starts.
7.2.1. Load File
Load an Ordinary File
Press “Menu” to enter the menu page→ press the “Up” and “Down” keys to select “Local Files” or
“USB Files”→ press [OK] to enter the corresponding file list page→ press [OK] to select the desired
IV-
machining file→ press
1 to load the selected file.
Load an ENG File with Tool Selection Function
Find the desired ENG file following the steps above-mentioned to load an ordinary file, and then
press [OK] to select the ENG file to be machined, and then press
selection page as shown in Fig. 7-4.
IV-
1 to automatically enter the tool
Number of tools: 2
Tool No.: 0
Cutter 1: [Flat Bottom]JD-6.00
Fig. 7-4 Tool selection page
Number of tools: the number of tools in this ENG file
Tool No.: current tool No., selected by pressing the “Up” and “Down” keys
Cutter: selected by pressing the “Up” and “Down” keys, displaying tool sequence number and
name
After parameters are set, press [OK] to load the file; after loading, the system will return to the
machining page automatically.
7.2.2. WCS Selection
WCS and MCS are switched by pressing the combination key
display is as shown in Fig. 7-5.
+
. And their screen
「64」Machining Operations of NK105G3
    "
