Specialized Concentrated Focused
Parameter
Meaning
Setting range
specified by S command in the file belongs to which
gear, then the speed of the gear will be enabled as
the current spindle speed, instead of the speed
specified by the S command directly.
the system
No: Enable the spindle
command in the
machining file
6.5. Mfr Param (Manufacturer Parameters)
Velocity Parameters
Parameter
Decel. Dist.
Approach Speed
Sgl Axis Acc.
Max. Turn Acc.
Jerk
Max. Feedrate
Meaning
Setting range
To protect tools, the machine tool will decelerate (at
[Approach Speed]) when approaching the target
position during positioning. This parameter is used to 0~999mm
specify the distance from the decelerating position to
the target position.
It is the feed speed of the tool when approaching
workpiece during positioning (the distance between Jump speed ~
the tool and workpiece is smaller than deceleration Machining speed
distance).
Description of the acceleration/
capability of each feed axis, in “mm/s2”
deceleration
0.001~100000.0mm/s2
The max. acceleration of feed motion on adjacent 0.001~100000.0 mm/s2
axes
The change rate of acceleration of single axis 0.001~100000.0 mm/s3
(acceleration’s acceleration)
To set the maximum speed of X,Y,Z axes
0~Maximum machining
speed
ShortSegSpdLmt Whether to enable speed limit for short segments
Yes: Valid; No: Invalid
SpdLmt Length The max. length of short segments
0.001~100000mm
0: Not disposed
Z Down Option The mode of Z axis downward cut
1: Only Z axis
2: XYZ synchronization
The downward cut speed of Z axis under G01 0~Max. Speed of Z
Z PlungeCutSpd
downward cut
axis
Ref Cir Radius See below for explanation.
0.001~100000.0 mm
Ref Cir. Speed
Reference circle is the reference for the machining of
circular workpiece. The max. speed of reference
circle refers to the max. speed of machine in
machining this circle without obvious vibration.
Min. speed of arc
machining ~ Machining
speed
Jump Speed
The max. speed for the stepper motor at start-up [Approach Speed]~
without acceleration
Machining speed
After the installation of a machine tool, you can make the machine process a circle, in which
「48」Menu Page
    "
