5.5. Spindle Debugging
This system can control spindle motor through parameters of “Spindle Gears”, “ON/OFF Delay”,
“Initial Gear” and “Max. Spdl Speed”. Spindle speed can also be changed during machining under the
condition that the interface board and inverter have been well connected.
5.5.1. Spindle Setup
Press the “Menu” key→ 5. Mfr Param→ 6. Spindle Set, and then press the [OK] to enter the
spindle setup interface, in which press the “Up” or “Down” key to select the corresponding parameter
for modification.
Spindle Gears
Currently, 8 gears are supported.
ON/OFF Delay
Since it takes some time for the spindle to reach the rated rotary speed or stop completely, tool
damage or a scrap may happen if machining starts before the spindle reaching the rated rotary speed
or other actions are performed before the spindle stopping completely. This parameter set the delay
time for the spindle to reach the set spindle speed or stop completely when turned ON or OFF.
Initial Gear
It sets the default gear when the spindle started, and its value should be smaller than the total
gear number of the spindle. Otherwise, the input value is invalid. If the input value of “Spindle Gears” is
smaller than that of “Initial Gear”, the setup is not effective, either.
Modification to this parameter becomes effective after reboot.
Max. Spdl Speed
It refers to the max. rotary speed of the spindle; its value is consistent with the setting of inverter.
Modification to this parameter becomes effective after reboot.
5.5.2. Park MCS Site
Press the “Menu” key→ 3. Operations→ 5. Park MCS Site, and then press the [OK] to enter the
interface of “Park Mode” and “Park Site”, as shown in Fig. 5-7. The position of the spindle after the end
of machining can be set here.
